Tool for Selecting Coils for Wireless Power Transfer

Wurth Elektronik now offers developers with a tool—Mix and Match—to help select the right transmitter and receiver coils. Mix and Match is a new tool in the RED EXPERT Toolbox. Also like the other tools in RED EXPERT, Mix and Match shows online accessible product specifications. While some combinations of transmitter and receiver coils work well, some combinations aren’t good matches. Mix and Match helps you find suitable coils for your application.Wurth MixMatch

The free Mix and Match online tool will be expanded as time goes on. In Q4 2016, Wurth is slated to publish data on the resonant circuits of the coil combinations tested.

Source: Wurth Elektronik
