Radiation-Hardened QDR-II+ SRAMs Achieve QML Class V Certification

Cypress Semiconductor Corp. recently announced its radiation-hardened (RadHard) 72-Mb Quad Data Rate II+ (QDR-II+) SRAMs and 4-Mb fast asynchronous SRAMs have achieved Qualified Manufacturers List Class V and Class Q requirements—the highest standards of quality and reliability for aerospace-grade ICs.CypressSRAM

The 72-Mbit QDR-II+ SRAMs deliver industry-leading throughput performance up to 36 Gbps by leveraging the ability to read and write data simultaneously. This throughput, combined with complete random access of data and free memory controllers for FPGAs, enables reconfigurable computing platforms that allow satellites to be reprogrammed while in space. The devices also feature the industry’s lowest latency and are ideal for radar and networking applications used in space

Both new SRAM families employ Cypress’s patented RadStop technology, which enables uncompromised functionality in the face of radiation up to 300 krads. The devices are manufactured in the Cypress’s fabrication facility in Bloomington, Minnesota, which is Microelectronics Trusted Category 1A accredited.

The radiation-hardened 4-Mbit devices deliver access times of 10 ns at 85°C and 12 ns at 125°C. They are also the first 90-nm, QML-V qualified devices of their kind and are ideal for a wide range of space and military applications.

Cypress’s RadStop technology combines manufacturing process hardening and proprietary design techniques. With RadStop technology, the SRAMs deliver single event latch-up immunity and single event functional interrupt immunity at temperatures as high as 125°C.

The Rad-Hard 72-Mb QDR-II+ SRAMs are available in a 165-column grid array (CGA) package. The devices come in the following four part numbers and configurations with equivalent Defense Supply Center Columbus (DSCC) part numbers:

— ADVERTISMENT—

Advertise Here

  • CYRS1542AV18-250GCMB (x18 bus width, burst of 2); Class V part number: 5962F1120101VXA
  • CYRS1543AV18-250GCMB (x18 bus width, burst of 4); Class V part number: 5962F1120102VXA
  • CYRS1544AV18-250GCMB (x36 bus width, burst of 2); Class V part number: 5962F1120201VXA
  • CYRS1545AV18-250GCMB  (x36 bus width, burst of 4); Class V part number: 5962F1120202VXA

The CYRS1049DV33-12FZMB (5962F1123501VXA) 4-Mb fast asynchronous SRAMs are available in a 36-pin ceramic flat package.

Source: Cypress Semiconductor
