Quad Channel DPWM Step-Down Controller

Exar Corp. has introduced the XR77128, a universal PMIC that drives up to four independently controlled external DrMOS power stages at currents greater than 40 A for the latest 64-bit ARM processors, FPGAs, DSPs and ASICs. DrMOS technology is quickly growing in popularity in telecom and networking applications. These same applications find value in Exar’s Programmable Power technology which allows low component count, rapid development, easy system integration, dynamic control and telemetry. Depending on output current requirements, each output can be independently configured to directly drive external MOSFETs or DrMOS power stages.EX045_XR77128

The XR77128 is quickly configured to power nearly any FPGA, SoC, or DSP system through the use of Exar’s design tool, PowerArchitect, and programmed through an I²C-based SMBus compliant serial interface. It can also monitor and dynamically control and configure the power system through the same I²C interface. Five configurable GPIOs allow for fast system integration for fault reporting and status or for sequencing control.  A new Arduino-based development platform allows software engineers to begin code development for telemetry and dynamic control long before their hardware is available.

The XR77128 is available in a RoHS-compliant, green/halogen free space-saving 7 mm × 7 mm TQFN. It costs $7.75 in 1000-piece quantities.

Source: Exar Corp.
