New Ready-to-Use Wireless PCB Antennas

Pulse Electronics recently introduced three design-ready, standard, wireless printed circuit board antennas. Intended for tablets, laptops, and mobile devices, the SH0319D/E/W antenna family provides wireless signal reception ranging from dual bands to multibands covering GPS, Glonass, WLAN/dual-band WIFI, and GSM900/1800. Pulse Elect antenna

The SH0319D and SH0319E are flexible dual-band, coaxial feed antennas with a single feed point that cover 2.4- and 5-GHz frequencies. The antenna size is 8 mm × 15 mm × 1.08 mm (W x L x H) with a total size of 38 mm × 15 mm × 1.08 mm. The SW0159W is a coaxial feed multiband GPS/WLAN and GSM900/1800 antenna that covers frequency ranges of 1.5/2.4 GHz, 5 GHz, and 900/1,800 MHz. It has dual feed points. The antenna size is 70 mm × 10 mm × 1 mm with a total size of 70 mm × 15 mm × 1 mm.



Source: Pulse Electronics
