Linear LT3999 DC/DC Transformer Driver

Linear Technology recently launched the LT3999 monolithic push-pull isolated DC/DC transformer driver with two 1-A current limited power switches. It operates over an input voltage of 2.7 to 36 V and is targeted for power levels up to 15 W, making it a good option for a variety of industrial applications.

Source: Linear Technology

Source: Linear Technology

The LT3999’s features include:

  • Wide VIN range: 2.7 to 36 V
  • Dual 1-A switches
  • Programmable switching frequency: 50 kHz to 1 MHz
  • Synchronizable to an external clock up to 1 MHz
  • Duty cycle control for output voltage regulation
  • Low noise topology
  • Programmable input over- and under-voltage lockout
  • Cross-conduction prevention circuitry
  • Extended and industrial grades: –40° to 125°C operating junction temperature
  • Automotive temperature grade: –40° to 150°C operating junction temperature
  • Military temperature grade: –55° to 150°C operating junction temperature

The LT3999’s 1,000-piece price starts at $2.75 each for the E-grade.

Source: Linear Technology
