12.1-Inch Industrial Touch Panel PC is Customizable

Axiomtek has introduced its newest industrial-grade touch panel computer, the P1127E-500. This robust all-in-one computer comes in a 12.1-inch XGA TFT LCD display size, with a 5-wire resistive touchscreen and 500 nits of brightness. Its scalable CPU options, rich and customizable I/Os and optional, easy-to-integrate features were designed to deliver true value to customers. Its high flexibility will allow for faster project deployment for a wide range of industrial applications. The P1127E-500 is well-suited for use in multimedia kiosks or as a human machine interface (HMI) for industrial automation applications.

The P1127E-500’s high flexibility allows for use in challenging operating conditions, with its robust features such as its IP65-rated spill/dust-resistant front bezel, as well as its operating temperature range of 0°C to +50°C (0°F to +122°F). For scalability, the touch panel PC offers the choice between three Intel CPU categories: the high performance 7th/6th generation Intel Core i7/i5/i3 socket LGA1151; the mid-level Celeron; or the entry-level Pentium processor, all with the Intel H110 chipset. For greater customizability, the P1127E-500 offers a choice of either one PCIe x4 slot or one PCI slot for integration with a variety of add-on cards. Its rich I/Os include three RS-232 ports, one RS-232/422/485 port, four USB 3.0 ports, two USB 2.0 ports, two Gigabit Ethernet ports, one audio (Mic-in/Line-out), one VGA port, one HDMI port and one DisplayPort. It is also equipped with dual DDR4-2133 Long-DIMM sockets for up to 32GB of system memory and one 2.5” SATA HDD for storage.

The P1127E-500 features built-in speakers, an optional Wi-Fi 802.11 b/g/n module and a WLAN antenna. It can be mounted using a desktop stand, VESA arm or wall mounting. It supports a variety of operating systems including Windows 10, Windows 8.1 and Windows 7.



Some Key Features:

  • 1” XGA TFT LCD display with 5-wire resistive touchscreen and 500 nits of brightness
  • 7th/6th generation Intel Core i7/i5/i3 socket LGA1151, Celeron® or Pentium® processors with Intel H110 chipset
  • Two GbE LAN port, four COM ports, two USB 2.0 ports and four USB 3.0 ports
  • Choice of PCIe x4 slot or PCI slot
  • Dual DDR4-2133 Long-DIMM sockets for up to 32GB of system memory
  • Operating temperature range of 0°C to +50°C (0°F to +122°F)
  • Mounting options include panel mount, wall mount, VESA arm and desktop stand
