1 W DC-DC Converters Medical Approved

MINMAX Technology has announced the MINMAX MAU01M / MSCU01M series, a new range of high performance 1 W medical safety approved DC-DC converters with encapsulated SIP-7 & SMD packages. They are specifically designed for medical applications. The series includes  models available for input voltages of 4.5 VDC to 5.5 VDC, 10.8 VDC to 13.2 VDC, and 21.6 to 26.4 VDC. The I/O isolation is specified for 4,000 VAC with reinforced insulation and ated for a 300 Vrms working voltage.

40e5a6c0900620d4a836fb17d0ef3ecbFurther features include short circuit protection, a low leakage current of 2 μA max. and operating ambient temperating range of -40°C to 95°C. This is achieved without de-rating and with a high efficiency of up to 84%. The MAU01M / MSCU01M series conforms to the 4th edition medical EMC standard. It meets 2xMOPP (Means of Patient Protection) per 3rd edition of IEC/EN 60601-1 & ANSI/AAMI ES60601-1. The MAU01M / MSCU01M series offer an economical solution for demanding medical instrument applications that require a certified supplementary and reinforced insulation system to comply with latest medical safety approvals under the 2x MOPP requirements.

MINMAX Technology | www.minmaxpower.com
