The July issue of Circuit Cellar magazine is out next week! This 84-page publication will make a satisfying thud sound when it lands on your desk and it’s crammed full of excellent embedded electronics articles prepared for you.
Not a Circuit Cellar subscriber? Don’t be left out! Sign up today:
Here’s a sneak preview of July 2019 Circuit Cellar:
CONNECTED SYSTEMS IN ACTION
in Railway Systems
Railway systems keep getting more advanced. On both the control side and passenger entertainment side, embedded computers and power supplies play critical roles. Railway systems need sophisticated networking, data collection and real-time control, all while meeting safety standards. Circuit Cellar Chief Editor Jeff Child looks at the latest technology trends and products relevant to railway applications.
IoT Interface Modules
The fast growing IoT phenomenon is driving demand for highly integrated modules designed for the IoT edge. Feeding those needs, a new crop of IoT modules have emerged that offer pre-certified solutions that are ready to use. This Product Focus section updates readers on this technology trend and provides a product album of representative IoT modules.
TECHNOLOGIES AND TECHNIQUES FOR ENGINEERS
FPGA Signal Processing
Offering the dual benefits of powerful signal processing and system-level integration, FPGAs have become a key technology for embedded system developers. Makers of chip and board-level FPGA products are providing complete solutions to enable developers to meet their application needs. Circuit Cellar Chief Editor Jeff Child explores the latest technology trends and product developments in FPGA signal processing.
Macros for AVR Assembler Programming
The AVR microcontroller instruction set provides a simplicity that makes it good for learning the root principles of machine programming. There’s also a rich set of macros available for the AVR that ease assembler-level programming. In this article, Wolfgang Matthes steps you through these principles, with the goal of helping programmers “think low-level, write high-level” when they approach embedded systems software development.
Inrush Current Limiters in Action
At the moment a high-power system is switched on, high loads can result in serious damage—even when the extra load is only for short time. Inrush current limiters (ICLs) can help prevent these issues. In this article, TDK Electronics’ Matt Reynolds examines ICLs based on NTC and PTC thermistors, discussing the underlying technology and the device options.
A Look at Cores with TrustZone-M
It’s not so easy to keep up with all the new security features on the latest and greatest embedded processors—especially while you’re busy focusing on the more fundamental and unique aspects of your design. In this article, Colin O’Flynn helps out by examining the new processor cores using TrustZone-M, a feature that helps you secure even low-cost and lower power system designs.
PROJECTS THAT REUSE & RECYCLE
Energy Monitoring Part 2
In Part 1 of this article series, George Novacek began describing an MCU-based system he built to monitor his household energy. Here, he continues that discussion, this time focusing on the electrical power tracking module. As the story shows, he stuck to a design challenge of building the system with as many components he already had in his component bins.
Variable Frequency Drive Part 1
Modern appliances claim to be more efficient, but they’re certainly not designed to last as long as older models. In this project article, Brian Millier describes how he reused subsystems from a defunct modern washing machine to power his bandsaw. The effort provides valuable insights on how to make use of the complete 3-phase Variable Frequency Drive (VFD) borrowed from the washing machine.
FUN PROJECT ARTICLES WITH ALL THE DETAILS
Windless Wind Chimes (Part 2)
In part 1 of this article series, Jeff Bachiochi built a system to simulate breezes randomly playing the sounds of suspended wind chimes. In part 2 the effort evolves into a less random, more orchestrated project. Jeff decided this time to craft a string of chromatically tuned chimes, similar to what an orchestra might use so the project could be used to play music. The project relies on MIDI, an industry standard music technology protocol designed to create and share music and artistic works.
Building a Smart Frying Pan
There’s almost no limit to what an MCU can be used for—-including objects that previously had no electronics at all. In this article, learn how Cornell University graduate Joseph Dwyer build a Microchip PIC32 MCU-based system that wirelessly measures and controls the temperature of a pan on a stove. The system improves both the safety and reliability of cooking on the stove, and has potentially interesting commercial applications.
EOG-Controlled Video Game
There’s much be to learned about how electronics can interact with biological signals—not only to record, but also to see how they can be used as inputs for control applications. With ongoing research in fields such as virtual reality and prosthetics, new systems are being developed to interpret different types of signals for practical applications. Learn how Cornell graduates Eric Cole, Evan Mok and Alex Huang use electrooculography (EOG) to control a simple video game by measuring eye movement.
Circuit Cellar's editorial team comprises professional engineers, technical editors, and digital media specialists. You can reach the Editorial Department at email@example.com, @circuitcellar, and facebook.com/circuitcellar
